PMAX 5600 Home Gym Smith Machine - Integrated Weight System

Regular price $1,739.99 $2,900.00 40% off
/
You save $1,160.01
  • 6-in-1 Functional Smith Machine
  • Perform 99+ Full-Body Exercises
  • 23 Pulley Positions for Cable Workouts
  • Dual 160 LB Selectorized Weight Stacks
  • 2,000 LB Weight Capacity for Heavy Lifts
Additional Attachment Options
Popular Accessories
Aluminum Pulley Kit
$159.99
$189.99
2" Color Bumper Plates
$679.00
$750.00
Leg Press Attachment
$169.00
RitKeep Rubber Flooring Gym Mats With EVA Foam
$119.00
RitKeep 7FT 700 LB Capacity Olympic Barbell
$175.00
$215.00
4FT EZ Curl Bar
$109.00
$189.00
Adjustable Leg Holder
$129.99
$159.99
Heavy-Duty Jammer Arms
$249.00
Extra Accessories
PMAX 5600 Weight Stack Add-On Plate Holders (Pair)
$89.00
RitKeep Barbell Squat Pad
$39.00
RitKeep All-In-One Adjustable Dumbbells (Pair)
$599.00
$749.00
RitKeep Aluminum Olympic Barbell Collars (Pairs)
$45.99
Gym Ankle Strap for Cable Machine (Pair)
$39.99
Cable Machine 5pcs Lat Pulldown Bar Combo
$169.00
$229.00
Pull Up Assist Band Set Premium Resistance Bands | RitKeep
$46.62
Six-sided Rubber Coated Hex Dumbbell Sets
$1,030.00
Warranty Options
1 Year Warranty
Extends the PMAX 5600 main frame warranty. Coverage begins after the original warranty expires.
$109.00
2 Year Warranty
Extends the PMAX 5600 main frame warranty. Coverage begins after the original warranty expires.
$209.00
3 Year Warranty
Extends the PMAX 5600 main frame warranty. Coverage begins after the original warranty expires.
$299.00
Review & Add To Cart
QTY
Price
PMAX 5600 Home Gym Smith Machine - Integrated Weight System | Red (2026 Version) / 320 LB / None
+1
$1,739.99
Shipping
Free
Total
More payment options

4 Interest-Free Installments under $3,000
30-Day Money-Back Guarantee
2-Year Warranty for Your Machine
8268369679669248769799888739848679719279958879830000000000000000

PMAX 5600 Home Gym Smith Machine - Integrated Weight System

Red (2026 Version) / 320 LB / None - $1,739.99
  • Red (2026 Version) / 320 LB / None - $1,739.99
  • Red (2026 Version) / 320 LB / RAB 3000 (Red) +$209 - $1,948.99
  • Red (2026 Version) / 320 LB / RAB 3000 (Black) +$209 - $1,948.99
  • Red (2026 Version) / 320 LB / RAB 2000 +$169 - $1,908.99
  • Red (2026 Version) / 400 LB +$200 / None - $1,939.99
  • Red (2026 Version) / 400 LB +$200 / RAB 3000 (Red) +$209 - $2,148.99
  • Red (2026 Version) / 400 LB +$200 / RAB 3000 (Black) +$209 - $2,148.99
  • Red (2026 Version) / 400 LB +$200 / RAB 2000 +$169 - $2,108.99
  • Black (2026 Version) / 320 LB / None - $1,739.99
  • Black (2026 Version) / 320 LB / RAB 3000 (Red) +$209 - $1,948.99
  • Black (2026 Version) / 320 LB / RAB 3000 (Black) +$209 - $1,948.99
  • Black (2026 Version) / 320 LB / RAB 2000 +$169 - $1,908.99
  • Black (2026 Version) / 400 LB +$200 / None - $1,939.99
  • Black (2026 Version) / 400 LB +$200 / RAB 3000 (Red) +$209 - $2,148.99
  • Black (2026 Version) / 400 LB +$200 / RAB 3000 (Black) +$209 - $2,148.99
  • Black (2026 Version) / 400 LB +$200 / RAB 2000 +$169 - $2,108.99

VIDEO

Video Guide

ACCESSORIES

Black Friday Banner

DESCRIPTION

Ritkeep PMAX 5600 Home Gym Smith Machine is the top of our Premium Series lineup. It combines 6 Strength Training Machines in ONE SINGLE MACHINE, including the Power Rack, Crossover System, Smith Machine, Chin-up Station, Dip Station, and Low Row, making it perfect for strengthening different muscle groups and executing comprehensive workouts without switching between equipment!

Made with a 14-gauge heavy-duty steel frame reinforced with a durable powder-coated finish.

  • Machine Weight – 653 lb (including Dual 160 lb Weight Stacks)
  • Machine Dimension – 59.57" D x 80.12" W x 86.06" H
  • Maximum Capacity Smith Machine Bar – 440 lb
  • Maximum Loading Capacity — 2,000 lb
  • Please note: This machine requires assembly. The Smith bar is compatible with both 29mm and 50mm weight plates, but it cannot connect to the weight stacks. To use the Smith system properly, you will need to load weight plates onto the Smith bar.
  • Disclaimer: Weight plates are not included. The Smith barbell is included.

THE HIGHLIGHT: SMITH MACHINE WITH PULLEY SYSTEM

  • The cable pulley, each with a dual 160 lb pin-selection weight stack system, can be used both simultaneously and independently of each other.
  • The 2:1 pulley ratio ensures ultra-controlled movement across the full range of cable exercises.
  • With 23 adjustable positions, it provides smooth motion, extended travel, and enhanced responsiveness, making it ideal for functional training.
  • During an arm workout utilizing supersets, you can effortlessly alternate between bicep and tricep exercises without attaching a different handle.
  • Smooth-rolling pulley with high-quality ball bearings, allowing you to do exercises such as lat pulldowns, rowing, single-arm cable rows, bicep curls, tricep pushdowns, cable flys, chest press, cable deadlifts, squats, etc.

HOME GYM SMITH MACHINE WITH A 50MM BARBELL

  • With the vertical Smith System, which includes the Smith barbell, you can train all muscle groups without needing an additional free-weight barbell.
  • Safer than free weights. If you reach muscle failure, you can secure the bar on one of the 12 safety silver pegs.
  • The fixed vertical bar path provides greater stability, helping you isolate target muscles.
  • Ideal choice for people who don’t have access to a spotter or want to work out alone.

SPECIFICATION

Dimensions & Footprint

Rack Weight 653 lb
Rack Height 86.06 in
(Allow at least 5" overhead clearance for pull-ups)
Rack Width (Including Smith Bar) 80.12 in
(Allow 20" of side clearance to load plates comfortably)
Rack Depth (Including Attachments) 59.57 in
Inside Width 43.3 in
Inside Depth 46.9 in
Smith Bar Weight 35 lb
Smith Bar Length 80.12 in
Smith Bar Sleeve Length 11.4 in


Cable Pulley

Weight Stack 320 lb (Standard) / 400 lb (Upgraded)
Pulley Ratio 2:1
Pulleys Nylon
Cable 4-Layer Encased Steel
Cable Pulley Rotation 200°
Cable Head Rotation 360°
Vertical Adjustment 23 Levels


Max Load Capacity

Machine 2000 lb
Cable 1500 lb
J-Hooks 1500 lb
Safety Spotter Arms 1000 lb
Pull-Up Bar 500 lb
Dip Station 350 lb
Lat Pulldown Bar 300 lb
Straight Bar 300 lb
Landmine & T-Bar 600 lb


Frame

Steel Type 14-Gauge Alloy Steel
Square Tube 50 mm x 50 mm
Metal Thickness 2 mm
Coating Powder Coated


PMAX-5600 Installation

📖 Installation Manual: Download ▶️ Installation Video: Watch

WARRANTY

Warranty Period

Ritkeep provides a comprehensive warranty coverage for a duration from the date of purchase. During this period, we guarantee that your product will be free from any defects in material, functionality, and workmanship. The warranty is exclusively applicable to the original purchaser of the product, as long as you remain the owner. It is important to remember that the warranty is non-transferable.

Construction

FOR ALL WARRANTIES * Warranty may be voided for any product which has been damaged due to negligent or faulty use, alteration, maintenance, storage or handling by the user. Any specific issues regarding a RitKeep product with which a customer is not satisfied will be reviewed on a case-by-case basis. Please note that our warranty does not apply to product or barbell service and maintenance. We recommend you properly service and maintain your product for life long product longevity.

** Warranty against bending does not cover any bar which has been damaged due to negligent or faulty use, alteration, maintenance, storage or handling by the user. Negligent or faulty use includes abusive dropping of the bar (i.e., dropping the bar on a box, bench, spotter arms or pins in a power rack, excessive dropping with insufficient or damaged bumpers, excessive dropping with iron plates, excessive dropping on concrete or similar surfaces, and similar usage). Any specific issues regarding a RitKeep product with which a customer is not satisfied will be reviewed on a case-by-case basis.

Material Warranty
Frames 2 Year Warranty

Pull-Down Bar, Dip Bar, Landmine, T-bar, Safety Arm, D-Shape Handle, J-Hooks

1 Year Warranty
Wheels, Cables 90 Day Warranty
Dumbbells 2 Year Warranty
Weight Plate 2 Year Warranty
Weight Bench 1 Year Warranty

To learn more about RITKEEP's Warranty Policy, please click here.



Lift Confidently. Move Seamlessly.

Effortless Adjustments. Freedom From Every Angle.

All-in-One Function. All-in-Place Storage.

Pull-Up Bar

Multi-grip pull-up bar offers various hand positions to improve grip strength and spinal stability.

Dual Pulley System

Dual cable crossovers with independent weight stacks help evenly balance your exercises.

Smith System

Equipped with bearings for enhanced smoothness and stoppers for optimal protection.

Wide & Narrow Dip Bar

With solid support and stability, it works the abs, triceps, deltoids, and pectorals.

Dual Spotter Arms

Offers key support and versatility for weightlifting, removing the need for a spotter for safe training.

Weight Storage

Simplify weight storage with 6 convenient plate holders, which helps you save more space.

Low Row Landmine

Targets back and core muscles with controlled rotational rows for more effective lifting.

Foot Pedals

Ideal for seated rows, working upper body muscles to boost posture, balance, and strength.

Frequently Asked Questions

Can the PMAX-5600 weight stack be upgraded with additional weight?

Yes. The PMAX-5600 weight stack can be upgraded to 200 LB per side. If you need more resistance, you can add our Weight Stack Plate Holders. This add-on attachment supports an additional 120 LB per side.

What exercises does the PMAX-5600 target?

The PMAX-5600 supports 99+ full-body exercises, including bench presses, squats, rows, shoulder presses and more. With the Smith bar adjustable from 13.9" to 69.7", you can perform a wider range of movements, including overhead presses, hip thrusts, and Romanian deadlifts.

Can the PMAX-5600 be customized with different attachments?

Absolutely. The PMAX-5600 features 1" rack holes and supports a wide range of standard rack attachments, allowing you to easily integrate your existing accessories.

What training systems are integrated into the PMAX-5600?

The PMAX-5600 combines 6 training systems in one machine: power rack, crossover system, Smith machine, chin-up station, dip station, and low row station.

What is the cable pulley ratio of the PMAX-5600?

The PMAX-5600 features a 2:1 cable pulley ratio. When you select a 50-pound weight (ignoring friction), the effective resistance you feel at the handle is approximately 25 pounds.

Does the PMAX-5600 need to be bolted to the floor?

No. The PMAX-5600 features reinforced dual rear crossbars and dual diagonal support bars, providing excellent stability for heavy lifting and cable exercises without requiring floor mounting.
